Apple iPhone 17 Pro Max Key Features
Apple iPhone 17 Pro Max Specifications
General & Launch
- Announcement date
- 2025-09-09
- Release date
- 2025-09-19
- Availability
- Available
- Markets / regions
- International model A3526; some overseas models are eSIM-only
- Regional model codes
- iPhone 17 Pro Max; A3526 (international), A3257 (US), A3525 (selected eSIM regions), A3527 (China)
Processor & Software
- Operating system
- iOS 26 at launch
- User interface
- Apple iOS
- Chipset / SoC
- Apple A19 Pro
- Fabrication process (nm)
- 3 nm
- CPU
- 6-core CPU: 2 performance + 4 efficiency cores
- GPU
- Apple 6-core GPU with Neural Accelerators; hardware-accelerated ray tracing
- AI / NPU
- 16-core Neural Engine
- Extra Features
- Apple Intelligence (feature and language availability varies); vapour-chamber cooling
Performance Benchmarks
- Thermal throttling test
- Apple-designed vapour chamber and aluminium unibody heat spreader (manufacturer design)
- Extra Features
- No exact-model benchmark results entered; values left blank without verified test methodology
Build & Design
- Dimensions
- 163.4 × 78.0 × 8.75 mm
- Weight
- 231 g (Apple international specification; regional configurations vary)
- Build materials
- Aluminium unibody; Ceramic Shield 2 front; Ceramic Shield textured matte glass back
- Available colors
- Deep Blue; Silver; Cosmic Orange
- Water / dust resistance
- IP68; rated 6m water depth for up to 30 minutes under laboratory conditions
- Foldable design
- No
- SIM tray
- Physical nano-SIM tray on A3526; none on certain regional models
- Buttons / controls
- Action button; Camera Control; side button; volume buttons
- Extra Features
- Extended full-width camera plateau; water resistance can diminish with wear
Display
- Display technology
- Super Retina XDR LTPO OLED; ProMotion; Dynamic Island
- Screen size
- 6.9 inches (6.86-inch measured standard rectangle)
- Resolution
- 2868 × 1320 pixels
- Pixel density (ppi)
- 460 ppi
- Refresh rate
- Adaptive up to 120Hz
- Brightness (nits)
- 1000 nits typical; 1600 nits HDR peak; 3000 nits outdoor peak
- HDR formats
- HDR; Dolby Vision; HDR10
- Aspect ratio
- Approximately 19.5:9
- Display protection
- Ceramic Shield 2; anti-reflective and oleophobic coating
- Always-on display
- Yes
- Extra Features
- True Tone; P3 wide colour; Haptic Touch; minimum brightness 1 nit
Network & Frequency
- Network technology
- GSM / UMTS / HSPA+ / LTE / 5G NR (sub-6GHz; A3526)
- 2G bands
- GSM / EDGE 850 / 900 / 1800 / 1900 MHz
- 3G bands
- UMTS / HSPA+ 850 / 900 / 1700/2100 / 1900 / 2100 MHz
- 4G LTE bands
- FDD LTE 1,2,3,4,5,7,8,12,13,17,18,19,20,25,26,28,30,32,66; TDD LTE 34,38,39,40,41,42,48,53 (A3526)
- 5G bands
- FDD NR n1,n2,n3,n5,n7,n8,n12,n20,n25,n26,n28,n30,n66,n70,n75; TDD NR n38,n40,n41,n48,n53,n77,n78,n79 (A3526)
- Cellular data speed
- Gigabit-class LTE; sub-6GHz 5G with 4x4 MIMO (network dependent)
- SIM configuration
- Nano-SIM + eSIM (A3526); dual eSIM support
- eSIM support
- Yes; availability depends on regional model and operator
- VoLTE / VoWiFi
- Supported; operator dependent
- Extra Features
- Apple N1 wireless networking chip; Wi-Fi calling with supported carriers
Memory & Storage
- RAM
- 12GB (confirmed via Apple Xcode 26 data; not advertised in Apple consumer specs)
- Internal storage
- 256GB / 512GB / 1TB / 2TB
- Memory card slot
- No microSD slot
- Expandable storage
- No
- Memory configurations
- 12GB+256GB; 12GB+512GB; 12GB+1TB; 12GB+2TB
Cameras & Video
- Rear camera setup
- 48MP Fusion Main, 24mm equivalent, f/1.78, sensor-shift OIS
- Ultrawide camera
- 48MP Fusion Ultra Wide, 13mm equivalent, f/2.2, 120-degree field of view
- Telephoto camera
- 48MP Fusion Telephoto, 100mm equivalent, f/2.8, 4x optical; 8x optical-quality option
- Rear camera features
- Photonic Engine, Deep Fusion, Smart HDR 5, Night mode, ProRAW, LiDAR scanner, 48MP macro
- Optical stabilization
- Second-generation sensor-shift OIS (Main); 3D sensor-shift OIS (Telephoto)
- Rear video recording
- Up to 4K Dolby Vision at 120fps on Fusion Main; ProRes RAW, Apple Log 2, genlock support
- Front camera
- 18MP Center Stage front camera, f/1.9, autofocus
- Front camera features
- Square sensor; Center Stage for photos and calls; automatic portrait/landscape framing; Dual Capture
- Front video recording
- 4K Dolby Vision at up to 60fps; ProRes RAW / Apple Log 2 with compatible workflow
- Extra Features
- Adaptive True Tone flash, Photographic Styles; 40x digital photo zoom
Connectivity
- Wi-Fi
- Wi-Fi 7 (802.11be), 2x2 MIMO; Wi-Fi hotspot
- Bluetooth
- Bluetooth 6
- Positioning / GNSS
- Dual-frequency GPS; GLONASS; Galileo; QZSS; BeiDou; NavIC
- NFC
- Yes; NFC reader mode
- USB
- USB-C; USB 3 up to 10Gbps; DisplayPort video output
- Ultra Wideband
- Apple second-generation Ultra Wideband chip
- Tethering / hotspot
- Yes; Personal Hotspot
- Extra Features
- Thread networking support; Apple N1 wireless chip
Sound & Multimedia
- Speakers
- Built-in loudspeakers
- Stereo speakers
- Yes
- 3.5mm headphone jack
- No 3.5mm headphone socket
- Audio codecs / features
- Spatial Audio; Dolby Atmos; four studio-quality microphones; Audio Mix; wind noise reduction
Sensors & Security
- Sensors
- Face ID, LiDAR, barometer, gyroscope, accelerometer, proximity, dual ambient-light sensors
- Fingerprint reader
- No
- Face unlock
- Yes, Face ID
- Biometrics
- Face ID using TrueDepth system
- Extra Features
- Action button, Camera Control, Apple Intelligence
Gaming
- Cooling system
- Vapour chamber integrated into aluminium unibody
Durability & Repairability
- IP rating
- IP68: laboratory rating to 6 m for 30 min; resistance may diminish over time
- Glass / frame durability
- Ceramic Shield 2 front, Ceramic Shield back
- Battery serviceability
- Not user-removable
Pakistan Market
- PTA approval by variant
- Mercantile Pakistan distributor-listed units are PTA approved
- Local warranty
- 12 months Apple official warranty on units sold under Mercantile Pakistan
- Pakistan launch status
- Official Pakistan distributor listing available; worldwide release 2025-09-19
- Pakistan carrier band notes
- A3526 has nano-SIM + eSIM and sub-6GHz 5G; network/service support depends on operator
- In-box accessories / charger
- USB-C cable; compatible charger/accessories may be separate purchases
- Extra Features
- Distributor suggested retail rates may differ from shop prices and imported non-PTA units
Additional Information
- Model numbers
- A3526 international/Pakistan-region; A3257 US; A3525 selected eSIM regions; A3527 China
- Technical notes
- Research checked 2026-11-12. Source basis: Apple official technical specifications, Apple model identification, Mercantile Pakistan distributor pricing, and independent Xcode RAM confirmation. Featured AI illustration is not an official photograph.
Battery & Charging
- Battery capacity
- 4832 mAh (Apple does not publish mAh)
- Battery type
- Built-in rechargeable lithium-ion
- Wired charging
- USB-C fast charge: up to 50% in 20 min with compatible 40W+ adapter (sold separately)
- Wireless charging
- MagSafe up to 25W; Qi2 up to 25W with compatible charger
- Removable battery
- No
- Published battery-life test
- Apple international spec: up to 37h video playback, 33h streamed playback (laboratory claims)
- Extra Features
- Charger not necessarily included; actual battery endurance varies with use
Prices may vary by variant and local market.
The Apple iPhone 17 Pro Max price in Pakistan starts at Rs. 565,000 for the 256GB version on Mercantile’s listed PTA-approved price schedule. Higher-capacity versions cost Rs. 648,500 for 512GB, Rs. 732,000 for 1TB and Rs. 898,500 for 2TB. These are suggested distributor prices rather than guaranteed shop quotations. The phone combines Apple’s A19 Pro processor, a large 6.9-inch OLED screen, three 48MP rear cameras and extensive video tools. Before buying, compare the full package, not simply the lowest advertised price.
Price, storage options and availability in Pakistan
Mercantile lists the phone in Deep Blue, Silver and Cosmic Orange, with 256GB, 512GB, 1TB and 2TB storage. Its listed stock is PTA approved and comes with an Apple official warranty when purchased through the distributor’s channel. Individual shops may discount older inventory, charge more for a particular colour or sell an imported unit with different SIM arrangements. Consequently, an unusually low advertisement is not proof that the handset has local approval or distributor-backed coverage.
For most buyers, 256GB provides room for apps, photos and regular videos. The 512GB option is more comfortable for frequent 4K recording, long-term photo libraries and offline media. The 1TB and 2TB versions are specialist choices for people capturing substantial ProRes footage or keeping large files locally. There is no microSD card slot, so selecting the right capacity initially matters.
Design and 6.9-inch display
Apple uses an aluminium unibody with Ceramic Shield 2 over the front and Ceramic Shield on the back. The raised camera plateau spans the width of the phone. At roughly 163.4 × 78 × 8.75mm, it is a substantial handset rather than a compact model. The large screen is useful for maps, reading, editing photos and viewing documents, but one-handed use is harder and the weight may bother buyers who prefer smaller devices.
The Super Retina XDR OLED panel has 2868 × 1320 resolution at about 460 pixels per inch. ProMotion adjusts the refresh rate up to 120Hz, giving scrolling and animations a fluid appearance without requiring that maximum rate all the time. Always-On display, Dynamic Island, True Tone, HDR and a peak outdoor brightness claim of 3,000 nits complete the package. That peak is a controlled-condition specification, not a promise of continuous brightness everywhere.
A19 Pro performance, software and cooling
The A19 Pro contains a six-core CPU, six-core GPU with Neural Accelerators and a 16-core Neural Engine. It is paired with a vapour-chamber cooling system built into the metal structure. The combination is intended to maintain performance through demanding work such as editing high-resolution clips, gaming and switching between many apps. Apple introduced the handset with iOS 26 and Apple Intelligence features, although language and regional availability can differ.
Independent examination of Apple’s developer tools identifies 12GB of RAM, although Apple does not advertise an official RAM figure in its consumer specifications. Actual responsiveness will also depend on software, storage usage and the task being performed. A smooth experience is reasonable to expect from this hardware, but there is no justification for claiming an exact frame rate or benchmark score without testing the specific device.
Triple 48MP cameras and optical-quality zoom
The rear system has a 48MP Fusion Main camera, 48MP Ultra Wide camera and 48MP Fusion Telephoto camera. The main camera uses second-generation sensor-shift optical image stabilisation. The ultra-wide lens supports close-up photography, while the telephoto camera offers genuine 4x optical reach and an additional 8x optical-quality option using its imaging system. Importantly, the 8x claim should not be confused with a separate 8x optical lens.
Portrait photography, night scenes and flexible composition are the real reasons to consider this arrangement. Apple’s processing includes Photonic Engine, Smart HDR and photographic styles, while ProRAW gives experienced editors greater control. Image quality still depends on lighting, subject movement and shooting technique. Buyers who mainly take quick social-media photos may not use the telephoto and editing capabilities often enough to justify the premium.
18MP front camera and professional video tools
The 18MP Center Stage selfie camera uses a square sensor, autofocus and automatic framing features. It is especially practical for group photographs, video meetings and creators who need both portrait and landscape framing. Dual Capture can record with front and rear cameras simultaneously, which is useful for demonstrations, travel commentary and behind-the-scenes videos.
Rear video features include 4K Dolby Vision capture, ProRes RAW, Apple Log 2 and genlock support with compatible equipment. These are meaningful tools for people who edit footage rather than simply upload clips directly. Some high-end recording modes require compatible external storage, accessories or applications. The additional storage and workflow requirements should be considered before paying extra for a large-capacity configuration.
Battery endurance and charging
For the physical nano-SIM model, the local distributor reports a 4,832mAh lithium-ion battery. Apple’s regional specifications claim up to 37 hours of video playback and 33 hours of streamed playback, measured under defined conditions. Real use will vary with screen brightness, cellular signal, background applications, camera use and battery condition. These figures are guidance for comparison, not a guarantee of the hours each customer will receive.
With a compatible 40W or higher USB-C power adapter, Apple claims a charge of up to 50% in around 20 minutes. MagSafe and Qi2 wireless charging support up to 25W with suitable equipment. Chargers may be sold separately. Compared with phones advertising extremely high wired wattages, charging speed is not necessarily this iPhone’s main attraction; its emphasis is on endurance, wireless convenience and an integrated ecosystem.
5G, SIM support and daily connectivity
The international model sold for Pakistan typically supports a physical nano-SIM and eSIM, while some imported regional models have no physical SIM tray. Check the exact model number and SIM configuration before paying. Cellular capabilities include 4G LTE and sub-6GHz 5G, but service depends on local operator coverage and enabled bands. A phone being technically 5G-capable does not establish that a particular network will deliver 5G at your address.
Other connectivity features include Wi-Fi 7, Bluetooth 6, NFC, dual-frequency satellite positioning and USB-C with USB 3 transfer speeds up to 10Gb/s when appropriate accessories are used. Face ID replaces a fingerprint reader, and stereo speakers are built in. Satellite safety functions and some Apple services are subject to country, carrier and service availability, so they should not be assumed to operate in Pakistan without checking.
Strengths, drawbacks and buying advice
Pros: a large, sharp 120Hz OLED screen; powerful A19 Pro hardware; versatile 48MP camera system; long manufacturer-rated battery endurance; sophisticated video recording; generous storage choices; and a recognised local warranty channel. Cons: high entry price; large dimensions; no expandable storage or headphone jack; separate charging accessories; and regional differences in SIM and satellite features.
The iPhone 17 Pro Max makes the most sense for buyers who prioritise an expansive display, advanced video production, strong processing capability and the Apple ecosystem. It is less compelling if your main requirements are calls, messaging, simple photography or the lowest possible price. Before placing an order, request a written invoice showing the storage and colour, confirm warranty coverage, inspect the physical SIM arrangement and verify the handset’s IMEI through the official PTA process. Do not treat a seller’s words or a screenshot as proof of registration.
Editorial note: Specifications reflect Apple’s published technical information and Mercantile’s local product listing. Prices may change. No original performance testing is claimed. The featured image is an AI-generated illustration rather than an official Apple product photograph.
